Structured packings made of plastic

VFF's plastic structured packings complement the range and offer a further solution in this area. Structured packings are placed side by side inside the column with subsequent layers rotated at 90°. The outer packing segments are cut to fit round column cross-sections. If HT-polypropylene is used temperatures of approx. 100°C are admissible for long term operation.

The packings are characterised by a low specific pressure drop and a high hydraulic load. Even in the case of high irrigation densities of approx. 100 m³/(m³ x h) gas loading factors of 3 √ Pa are handled without difficulty.

Detailed information: Structured packings

Description

Specific surface area

[m²/m³]

Dimensions

[L x B x H in mm]

Wall thickness

[mm] (PP)

Specific weight

[kg/m³] (PP)

P 250A
VFF P 250A 250

max. 2400 x

600 x 600

0.35...1.5 28.5...122.1
P 150 B
VFF P 150 B
150

max. 2400 x

600 x 600

0.45...1.5 21.3...71.1
P 125 B
125

max. 2400 x

600 x 600

0.67...1.5 23.8...54.4
P 125 C
VFF P 125C 125

max. 2400 x

600 x 600

0.55...1.5 23.9...65.1

Subject to technical modifications. All details serve for preliminary information purposes only. Claims cannot be derived therefrom.
